JCC Lighting Part Number JC080105 Skytile 600x600mm 30W IP44 4000K 3000lm Tp(a) UGR <19 1-10V
Our Part Number: JC080105
£8797 GBP
£49548 GBP
Discounts Added at Cart so Buy More & Save More
5 in stock
🚛 - Delivered in 2 to 3 working days.
Product Description
JCC Lighting Skytile range of Led Lighting Product Code = JC080105
Skytile 600x600mm 30W IP44 4000K 3000lm Tp(a) UGR <19 1-10V
Meets TP(a) requirements, suitable for all applications UGR <19 as standard, designed to comply with BS EN 12464-1 lighting of workspace Ultra efficient 100LpcW DALI/1-10V and DSI Dimming versions available IP44 protection against dust and moisture Comes with non-dimmable flicker free driver as standard Suspension kits and surface mount boxes available Suitable for use with JCEM002 and JCEM002ST emergency remote packs
Skytile 600x600mm 30W IP44 4000K 3000lm Tp(a) UGR <19 1-10V
Meets TP(a) requirements, suitable for all applications UGR <19 as standard, designed to comply with BS EN 12464-1 lighting of workspace Ultra efficient 100LpcW DALI/1-10V and DSI Dimming versions available IP44 protection against dust and moisture Comes with non-dimmable flicker free driver as standard Suspension kits and surface mount boxes available Suitable for use with JCEM002 and JCEM002ST emergency remote packs
Product Specification
Manufacturer - JCC Lighting
Manufacturers Part Number - JC080105
JCC - Accredited Members -
LIA, ISO9001-2015, ISO14001-2015
JCC - UKCA Marked - Yes
JCC - CE Marked - Yes
JCC - Product Bar Code EAN-13 Number - 5052544116599
JCC - Primary Material - Aluminium
JCC -Beam Angle ° - 90
JCC - CRI: Ra - 80
JCC - Energy Rating - This product contains a light source of energy efficiency class F
JCC - Operating Temperature Range °C - -25 to +50
JCC - Dimmable - 1-10V
JCC - Power Factor Correction - 0.95
JCC - Total Harmonic Distortion (THD)% - 13
JCC - Output Voltage Max/Range (VDC) - 9-58
JCC - Class - II
JCC - Luminaire Circuit Wattage - 30
JCC - Rating(Amp) - 30
JCC - Operating Frequency Hz - 50/60Hz
JCC - Inrush current(Amps) - <15
JCC - Primary Running Current(Amp) - 0.17
JCC - Secondary running current(mA) - 700
JCC - Voltage Rating - 220-240
JCC - Dimming Protocol Compatibility - 1-10V
JCC - Warranty - 5 Year Warranty (inc 2 year on site)(See Website for terms and conditions)
JCC - Suitable For Zones - Outside zone 1
JCC - IP Rating - IP44
JCC - Method of fix - sits in 15mm and 25mm ceiling grid system
JCC - Height (mm) - 9.8
JCC - Length (mm) - 595
JCC - Color Finish - White
